Low Noise IPX56 Protection Sand And Dust Test Chamber With Programmable Touch Screen Controller

Ask Lasest Price
Certification :	CE,ISO
Price :	Negotiable
Brand Name :	YOUBI
Model Number :	UP-6316
Payment Terms :	T/T,D/P,Western Union,Paypal,Money Gram
Supply Ability :	30 Unit/month
Delivery Time :	10-15 work days

Add to Cart

Product Details
Company Profile

Low Noise IPX56 Protection Sand And Dust Test Chamber With Programmable Touch Screen Controller

up-6316 Low Noise Lab Sand and Dust Test Chamber Ipx56 Protection Test Equipment

Standard: IEC60529

Features:

Test area size is 1000*1000*1000mm D*W*H

Interior material is SUS304 stainless steel

Exterior material is Steel Plate with protective coating, color is blue

Dust is blown in test area by air motor

Dust re-cycle blowing by circulating pump

A heater fixed into test chamber to keep dust dry

Wiper is fitted to view window, window size is 35*45cm

Silicon seal for door

Programmable color display touch screen controller which located on right side of chamber

A stainless steel shelf is fixed above the sieve and funnel

Chamber inside equipped with power interface for test specimen

Bottom of chamber is fitted with circulating pump, vacuum pump, motor

Temperature sensor PT-100

Safety protection

Guarantee a long service lifetime

Easy to operate on control panel

380V, 50Hz

Technical Parameters :
Note: Chamber size can be customized according to customer request. We have experience of producing and installing walk in dust chamber.

Internal dimensions (mm)	80010001000
Overall dimensions (mm)	105014201820
Performance index
Normal wire diameter	50um
Normal width of a gap between wires	75um
The Talcum powder amount	2kg ~ 4kg/m3
Fight time	0 ~ 99H59M
Fan cycle time	0 ~ 99H59M
Specimen power outlet	Dust-proof socket AC220V 16A
Control system
Controller	5.7" programmable color display touch screen controller
	PC Link with software, R-232 interface
Vacuum system	Equipped with vacuum pump, a pressure gauge, air filter, pressure regulating triple, connecting tube
Circulating fan	Enclosed alloy low-noise motor, multi-vane centrifugal fan
Heating system	Independent Nichrome electronic heating system
Power supply	380V 50HZ;
Safety Devices	Electric leakage, short circuit, Over-temperature, motor overheating Over-current protection/ Power failure memory function for controller

Low Noise Lab Sand and Dust Test Chamber Ipx56 Protection Testing Chamber

Our service:
During the whole business process, we offer a Consultative Selling services.
1)Customer inquiry process:
Discussing testing requirements and technical details, suggested suitable products to customer to confirm.
Then quote the most suitable price according to customer requirements.
2)Specifications customize process:
Drawing related drawings to confirm with customer for customized requirements. Offer reference photos to show the appearance of the product. Then, confirm the final solution and confirm the final price with the customer.
3)Production and delivery process:
We will produce the machines according to confirmed PO requirements. Offering photos to show the production process.
After finishing production, offer photos to the customer to confirm again with the machine. Then do your own factory calibration or third-party calibration(as per customer requirements). Check and test all the details and then arrange packing.
Delivering the products is confirmed shipping time and informed the customer.
4)Installation and after-sale service:
Defines installing those products in the field and providing after-sales support.
FAQ:
1. Are you a Manufacturer? Do you offer after-sales service? How can I ask for that? And how about the warranty?
Yes, we are the one of professional manufacturers of Environmental Chambers, Leather shoe testing equipment, and Plastic Rubber testing Equipment... in China. Every machine purchased from our factory has 12 month warranty after shipment. Generally, we offer 12 months for FREE maintenance. while considering sea transportation, we can extend 2 months for our customers.
Moreover, If your machine doesn't work, you can send us an e-mail or call us we will try our best to find the problem through our conversation or by video chat if necessary. Once we have confirmed the problem, the solution will be offered within 24 to 48 hours.
2. What about the delivery term?
For our standard machine which means normal machines, If we have stock in the warehouse, is 3-7 working days;
If there is no stock, normally, the delivery time is 15-20 working days after payment is received;
If you are in urgent need, we will make a special arrangement for you.
3. Do you accept customization services? Can I have my logo on the machine?
Yes, of course. We can not only offer standard machines but also customized machines according to your requirements. And we can also put your logo on the machine which means we offer OEM and ODM service.
4. How can I install and use the machine?
Once you have ordered the testing machines from us, we will send you the operation manual or video in English version through Email.
Most of our machine is shipped with a whole part, which means it is already installed, you just need to connect the power cable and start to use it. And if it's necessary, we can also assist you to install your machine on-site.
